| Place of Origin: | Anhui, China |
| Brand Name: | Ewinall |
| Certification: | ISO,EMS,CCPIT,QMS,CE，QEMS |
| Model Number: | DCS-10ZD2 |
| Minimum Order Quantity: | 1 set |
|---|---|
| Packaging Details: | packed in wooden box |
| Delivery Time: | 20 days |
| Supply Ability: | 5 sets per day |
| Application: | Seeds And Nuts | Automatic Grade: | Semi-automatic |
|---|---|---|---|
| Driven Type: | Electric And Air | Voltage: | Up To Custormer |
| Power: | 1.1KW | Dimension(L*W*H): | 742*613*1800 |
| Function: | Filling/ Weighing/ Packing | Bag Type: | PP/PE Bags |
| Packing Speed: | 1000bags/hour | Warranty: | 12 Months |
| Controlling System: | PLC Control | Port: | Any Port In China |
| High Light: | Sunflower Seed Packaging Machine semi auto,70.8in mini weighing filling machine,0.7kw nuts packaging machine |
||
Sunflower Seed Packing Machine Nuts Packaging Machine
Small auto nuts and seeds packing machine with PLC system manufacturer
Applicant
Precise quantitative small packaging of granular materials in the miscellaneous grain industry such as sorghum, millet, mung bean, adzuki bean and melon seeds.
Features:
1. The specially designed cylinder airtight studio completely isolates the corrosion and abrasion of the cylinder by rice flour, dust and water vapor, which greatly extends the trouble-free operation time of the equipment.
2. The independent dual-cylinder feeding overcomes the difficulty that the sealing ring is easy to wear, which is unavoidable in the application of three-position cylinders that has plagued quantitative packaging equipment for many years.
3. The double feeding mechanism of gravity and special vibrator is adopted, which greatly improves the packaging accuracy and speed.
4. The new technology of adaptive pneumatic feeding gate automatically selects the feeding mode according to the specifications, so that each specification has a higher feeding speed.
5. Adopt international advanced high-precision weighing sensor and quantitative controller, the controller adopts high-performance A/D converter, the conversion rate can reach 200 times/sec, the input sensitivity is 0.5μν/d, the measurement accuracy is high, and the stability is good.
6. The specially designed multi-stage feeding mechanism, combined with the control algorithm of the controller, makes the packaging of the scale fast and accurate
7. Equipped with manual control mode, which can control the discharging and loose bag mechanism separately by manual operation, which is convenient for cleaning agglomerated and blocked materials
8. It has the functions of automatic statistics, printing and data communication of the number of packages and the volume of packages.
9. The parts in contact with the material are made of stainless steel, which is corrosion resistant and prolongs the service life of the equipment
10. With automatic drop correction function. Out of tolerance alarm.
11. Standard micro printer, optional plug-in carbon filling device, mobile manual lifting conveyor, continuous heat sealing machine.
Parameter
| DCS-10ZD2 packing scale | |
| Model | DCS-10ZD2 |
| weighing(kg) | 0.25-10 |
| Accurancy | X(0.5) |
| capacity(bag/h) | 600-960 |
| Division (g) | 1g |
| Electric | AC220V |
| Power | 0.7kw |
| Air | 0.4-0.5MP Air 16.7L/min |
| Advantage | Metering and packaging of grain materials such as rice, mung beans, soybeans and corn |
| Dimension:L×W×H | 742×613×1800(INCLUDE HOPPER 2200) |
MAIN COMPONENTS
| Name | Brand | Note |
| Weighing controller | GM | Reserved RS232/485 serial port, standard Modbus RTU communication protocol, data communication with peripheral management system; |
| (PLC) | OMRON(JAPAN) | |
| LOAD CELL | METLLER TOLEDO | |
| SOLENOID VALVE | MINDMAN | |
| CYLINDER | AIRTAC | |
| TOUCH SCREEN | DELTA |
